| POWER SOURCE (V/Ø/HZ) | 230/1/50 Hz |
|---|---|
| COOLING INPUT POWER (KW) | 8.80 |
| REFRIGERANT | R32 |
| NET DIMENSION – INDOOR (H X W X D) (MM) | 340 × 1150 × 280 |
| OPERATION RANGE (°CDB) | 18-55 |
| PIPING CONNECTIONS (SMALL / LARGE) (MM) | 9.52/15.88 |
| Input Power – Cooling (kW) | 2.50 |
| EER W/W | 3.52 |
| RUNNING CURRENT (A) | 11.0 |
| Moisture Removal-Cooling (l/h) | 2.7 |
| Max. Height Difference (m) | 30 |
| Max. Pipe Length (Pre-charge) (m) | 50 (20) |
| DRAIN PIPE DIAMETER (I.D./O.D.) (MM) | 13.8/15 to 16.8 |
| NET DIMENSION – OUTDOOR (H X W X D) (MM) | 788 x 940 x 320 |
| SOUND PRESSURE (INDOOR) | 53 dB(A) |
| SOUND PRESSURE (OUTDOOR) | 53 dB(A) |
| INDOOR AIRFLOW RATE (M3/H) | 1,520 |
| OUTDOOR AIRFLOW RATE (M3/H) | 3620 |
AC installation Charge:
AC Installation with Materials (Iron Angle, 10 RFT Copper-tube, Insulation, Electric-wire & Rapping) Tk. 11,500
Wall type frame or, floor type frame (any One).
Free delivery:
Within DMP areas only.
Warranty:
Compressor: 02 years
Spare-parts: 02 years
Service: 03 years
Note:
