| Outdoor Unit Model | AOGG-18CPTA-V |
|---|---|
| POWER SOURCE (V/Ø/HZ) | 220 / 1 / 50 |
| Input Power-Cooling (W) | 1880 |
| CSPF-Cooling | 4.63 |
| Moisture Removal-Cooling (l/h) | 1.9 |
| Airflow Rate-Indoor-High(m3/h) | 940 |
| Airflow Distance-Indoor (m) | 15 |
| Sound Pressure-Indoor-SP-Hi/Mid/Lo (dB(A)) | 49/46/41 |
| Sound Pressure-Indoor-SP-Qu (dB(A)) | 28 |
| Sound Pressure-Outdoor-SP (dB(A)) | 51 |
| Net Dimension (H×W×D)-Indoor-mm | 270 × 834 × 239 |
| Net Weight-Indoor-kg | 11 |
| Net Dimension (H×W×D)-Outdoor-mm | 541 × 663 × 290 |
| Net Weight-Outdoor-kg | 27 |
| Piping Connection (Small / Large) (mm) | 6.35/12.7 |
| Standard Pipe Length (m) | 7.5 |
| Max. Pipe Length (Pre-charge) (m) | 20 (10) |
| Add charge volume (g/m) | 20 |
| Max. Height Difference (m) | 15 |
| Operation Range-Indoor (˚C) | 18 – 32 |
| Refrigerant Charge (Type) (kg) | 0.70(R32) |
| Operation Range-Outdoor (˚C) | 18 – 52 |
| COOLING INPUT POWER (KW) | 5.28 |
| Outdoor Unit Model | AOGG-18CPTA-V |
|---|---|
| POWER SOURCE (V/Ø/HZ) | 220 / 1 / 50 |
| Input Power-Cooling (W) | 1880 |
| CSPF-Cooling | 4.63 |
| Moisture Removal-Cooling (l/h) | 1.9 |
| Airflow Rate-Indoor-High(m3/h) | 940 |
| Airflow Distance-Indoor (m) | 15 |
| Sound Pressure-Indoor-SP-Hi/Mid/Lo (dB(A)) | 49/46/41 |
| Sound Pressure-Indoor-SP-Qu (dB(A)) | 28 |
| Sound Pressure-Outdoor-SP (dB(A)) | 51 |
| Net Dimension (H×W×D)-Indoor-mm | 270 × 834 × 239 |
| Net Weight-Indoor-kg | 11 |
| Net Dimension (H×W×D)-Outdoor-mm | 541 × 663 × 290 |
| Net Weight-Outdoor-kg | 27 |
| Piping Connection (Small / Large) (mm) | 6.35/12.7 |
| Standard Pipe Length (m) | 7.5 |
| Max. Pipe Length (Pre-charge) (m) | 20 (10) |
| Add charge volume (g/m) | 20 |
| Max. Height Difference (m) | 15 |
| Operation Range-Indoor (˚C) | 18 – 32 |
| Refrigerant Charge (Type) (kg) | 0.70(R32) |
| Operation Range-Outdoor (˚C) | 18 – 52 |
| COOLING INPUT POWER (KW) | 5.28 |
