1. Cooling Capacity:

• Rated Cooling Capacity: 18,000 Btu/hr or 5.28 kW
• Range of Cooling Capacity: 5,500 - 21,500 Btu/hr or 1.61 - 6.3 kW

2. Energy Efficiency:

• Energy Efficiency Ratio (EER): 3.26 W/W or 11.11 Btu/hW
• Integrated Seasonal Energy Efficiency Ratio (ISEER): 3.24
• Energy Star Rating: 1.5 Star

3. Noise Level:

• Indoor Noise Level: 44/28 dBA (High/Low)
• Outdoor Noise Level: 53 dBA (High)

4. Electrical Data:

• Power Source: 1 / 230 / 50 (Phase/Voltage/Frequency)
• Power Consumption (Cooling): 1620 W
• Operating Current (Cooling): 7.4 A

5. Physical Specifications:

• Indoor Unit Dimensions: 1115290375 mm
• Outdoor Unit Dimensions: 913622371 mm
• Indoor Unit Weight: 13.20 kg (Gross), 11.60 kg (Net)
• Outdoor Unit Weight: 36.30 kg (Gross), 32.00 kg (Net)

6. Technical Information:

• Maximum Piping Length: 30 m
• Maximum Piping Height: 15 m
• Refrigerant Type: R410A
• Moisture Removal: 2.0 l/hr
• Air Circulation (Cooling): 17.9 ㎥/min
• Low Ambient Cooling Range: 16 ~ 46 ℃

7. Air Flow and Control:

• WindFree Cooling: No
• Auto Air Direction Control (Up/Down, Left/Right)
• Air Flow Control Steps (Cool/Fan): 5/4

8. Air Purification:

• Copper Anti-bacterial Filter
• Auto Clean (Self Cleaning)

9. Convenience and Smart Features:

• SmartThings and WiFi Embedded for App Connectivity
• AI Auto Cooling
• Filter Cleaning Indicator
• 24-Hour Timer
• Auto Restart

10. Operating Modes:

• Auto Mode, Fast Cool, Good Sleep, Eco Mode, Dehumidification, Fan Mode, Quiet

11. Smart Features:

• SmartThings App Support
• AI Auto Cooling
• WiFi Embedded
