3.5 kW (12,000 BTU) Inverter Split Air Conditioner – Energy Efficient Cooling with Wide Voltage Operation (160V–265V), R32 Refrigerant, ECONO Mode, PAM Control, Auto Swing Airflow & Smart Comfort Technology

Discover reliable and energy-efficient cooling with this 3.5 kW (12,000 BTU) inverter split air conditioner, designed to deliver optimal comfort for small to medium-sized rooms. With a cooling capacity ranging from 1.75 kW (5,970 BTU) minimum to 3.5 kW (12,000 BTU) maximum, this AC ensures stable performance, efficient temperature control, and reduced power consumption, making it an ideal solution for bedrooms, small offices, and compact living spaces.

Built with advanced inverter technology and intelligent airflow design, this air conditioner integrates essential features such as Power Chill Operation, ECONO Mode, Good Sleep Off Timer, PAM Control, Auto Swing airflow, and quiet indoor operation, providing a balanced combination of comfort, efficiency, and durability.

Efficient Cooling Performance for Small to Medium Rooms

• Cooling Capacity: 3.5 kW (12,000 BTU/h)

• Minimum Capacity: 1.75 kW (5,970 BTU/h)

• Maximum Capacity: 3.5 kW (12,000 BTU/h)

• Recommended Coverage Area: Up to 120 sq ft (approx.)

• Outdoor Operating Temperature Range: Up to 50°C

This AC is specifically designed for compact spaces, ensuring quick cooling and consistent temperature maintenance even in high ambient conditions.

Multiple Cooling Modes for Enhanced Comfort

This air conditioner offers several smart operating modes to match different user needs:

• Power Chill Operation: Rapid cooling for instant comfort

• ECONO Mode: Reduces electricity consumption while maintaining cooling efficiency

• Good Sleep Off Timer: Automatically adjusts temperature during sleep for better rest

These modes allow users to customize cooling performance according to their lifestyle and daily usage patterns.

Strong Airflow with Wide Coverage

• Airflow Volume: 13.4 m³/min (473 CFM)

The optimized airflow system ensures effective air circulation, distributing cool air evenly across the room and maintaining a comfortable indoor environment.

Dual Swing Airflow for Uniform Cooling

This AC is equipped with both vertical and horizontal auto swing functionality:

• Vertical Auto Swing (Up & Down)

• Horizontal Auto Swing (Left & Right)

This dual-direction airflow ensures that cool air reaches all corners of the room, eliminating hot spots and improving overall cooling efficiency.

Energy Efficient Inverter Technology

• Power Consumption: 1110W

• Voltage Supply: 230V, 50Hz, Single Phase

• Operating Voltage Range: 160V ~ 265V

• Current: 15A

Key energy-saving features include:

• Inverter compressor technology for variable speed operation

• ECONO Mode for optimized energy usage

• PAM Control for efficient power regulation

• Good Sleep Off Timer for nighttime energy savings

This system helps reduce electricity bills while maintaining consistent cooling performance.

Wide Voltage Operation for Stable Performance

This AC supports a wide operating voltage range of 160V to 265V, making it highly suitable for areas with unstable power supply.

Benefits include:

• Stable operation during voltage fluctuations

• Reduced risk of damage to internal components

• No need for external voltage stabilizers in many cases

• Reliable cooling performance in varying electrical conditions

Eco-Friendly R32 Refrigerant

This air conditioner uses R32 refrigerant, which is known for its:

• High energy efficiency

• Lower environmental impact

• Reduced global warming potential

• Better heat transfer capability

R32 is a modern refrigerant that contributes to both performance and sustainability.

Quiet Operation for Peaceful Environment

This AC is designed to operate quietly, making it ideal for bedrooms, study rooms, and offices.

• Indoor Noise Levels:

  • High: 40 dBA

  • Medium: 36 dBA

  • Low: 32 dBA

  • Very Low: 29 dBA

  • Ultra Low: 26 dBA

• Outdoor Noise Level: 51 dBA

The low-noise performance ensures minimal disturbance while maintaining effective cooling.

Smart Features & User Convenience

This air conditioner includes several intelligent features for convenience:

• Auto Restart Function: Automatically resumes operation after power outages

• Timer Function: Schedule operation as per your routine

• Sleep Mode: Maintains comfortable temperature during night

• Backlit Remote Control: Easy operation in low-light conditions

• Quiet Mode: Reduces noise for a more comfortable environment

These features enhance usability and overall user experience.

Flexible Installation Options

• Maximum Piping Length: 20 meters

• Maximum Height Difference: 15 meters

• Mounting Type: Wall-mounted split system

This flexibility allows installation in different room layouts with ease.

Compact and Durable Design

Indoor Unit:

• Dimensions: 298 mm (H) × 800 mm (W) × 229 mm (D)

• Weight: 14 kg

Outdoor Unit:

• Dimensions: 550 mm (H) × 765 mm (W) × 285 mm (D)

• Weight: 33 kg

The compact design ensures easy installation while maintaining durability and long-lasting performance.

Included Installation Accessories

• Indoor unit

• Outdoor unit

• Remote control with backlight

• User manual & warranty card

• Standard installation kit

• Connecting wires (limited length)

These accessories help simplify installation and setup.

Applications

This 3.5 kW (12,000 BTU) inverter AC is ideal for:

• Bedrooms

• Small living rooms

• Small offices

• Study rooms

• Studio apartments

• Compact commercial spaces

Warranty & Reliability

• 5 Years Compressor Warranty

• 1 Year Spare Parts Warranty

• Free Service Warranty

This warranty coverage ensures long-term reliability and peace of mind for users.

Why Choose This 3.5 kW Inverter AC?

• Efficient cooling for small to medium rooms

• Inverter technology for energy savings

• Wide voltage operation (160V–265V)

• ECONO Mode for reduced electricity consumption

• Dual swing airflow for uniform cooling

• Quiet indoor operation for comfort

• Eco-friendly R32 refrigerant

• Compact design with easy installation

• Smart features for convenient usage

• Reliable warranty support

Long-Term Benefits

• Lower electricity bills

• Consistent and stable cooling performance

• Reduced maintenance requirements

• Improved indoor air comfort

• Durable and dependable operation

Installation Requirements

For best performance:

• Ensure proper wall space for indoor unit

• Maintain adequate ventilation for outdoor unit

• Use stable electrical supply within supported voltage range

• Professional installation recommended

Conclusion

This 3.5 kW (12,000 BTU) inverter split air conditioner is a compact, efficient, and reliable cooling solution designed for everyday comfort. With advanced features like inverter technology, wide voltage operation, ECONO mode, dual swing airflow, PAM control, and smart convenience functions, it delivers consistent cooling while optimizing energy usage.

Its eco-friendly R32 refrigerant, quiet operation, durable construction, and flexible installation options make it a perfect choice for users looking for a balance of performance, efficiency, and affordability. Whether for residential or small commercial use, this AC ensures dependable cooling, enhanced comfort, and long-term value.
