5.28 kW (18,000 BTU) Inverter Split Air Conditioner – High Efficiency Cooling with Wide Voltage Operation (160V–265V), COANDA Airflow, ECONO Mode, PAM Control, Smart Diagnostics & Advanced Comfort Technology

Experience powerful, stable, and energy-efficient cooling with this 5.28 kW (18,000 BTU) inverter split air conditioner, designed to deliver reliable performance for medium to large-sized residential and commercial spaces. With a cooling capacity ranging from 1.7 kW (5,800 BTU) minimum to 5.5 kW (18,800 BTU) maximum, this air conditioner ensures flexible operation, consistent temperature control, and optimized energy consumption under varying load conditions.

Built with advanced inverter technology and modern airflow systems, this AC integrates features such as Power Chill Operation, ECONO Mode, Good Sleep Off Timer, PAM Control, Auto Swing airflow, and indoor quiet operation, making it a complete solution for users who demand both comfort and efficiency in one system.

Powerful Cooling Performance with Flexible Capacity

This inverter air conditioner adapts to different cooling demands efficiently.

• Cooling Capacity: 5.28 kW (18,000 BTU/h)

• Minimum Capacity: 1.7 kW (5,800 BTU/h)

• Maximum Capacity: 5.5 kW (18,800 BTU/h)

• Temperature Range: Outdoor operating up to 50°C

The inverter compressor adjusts its speed dynamically, ensuring consistent indoor temperature while minimizing energy usage.

Multiple Cooling Modes for Personalized Comfort

This AC is equipped with several intelligent modes to enhance comfort and flexibility:

• Power Chill Operation: Rapid cooling for quick temperature reduction

• ECONO Mode: Reduces energy consumption while maintaining comfort

• Good Sleep Off Timer: Optimizes temperature during sleep for better rest

• Indoor Quiet Operation: Minimizes noise for a peaceful environment

These modes allow users to tailor cooling performance based on daily needs and preferences.

Efficient Airflow System for Uniform Cooling

• Airflow Volume: 16.2 m³/min (572 CFM)

The strong airflow ensures efficient circulation of cool air throughout the room, maintaining uniform temperature and eliminating hot spots.

Dual Swing Airflow for Better Distribution

This AC features both vertical and horizontal auto swing functions:

• Vertical Auto Swing (Up & Down)

• Horizontal Auto Swing (Left & Right)

This dual swing system ensures that cool air reaches every corner of the room, providing even cooling distribution and enhanced comfort.

Energy Efficient Inverter Technology

This air conditioner is designed with inverter technology and PAM control for optimized energy performance.

• Power Consumption: 1740W (Nominal)

• Operating Range: 431W (Min) ~ 2025W (Max)

• Voltage Supply: 230V, 50Hz, Single Phase

• Operating Voltage Range: 160V ~ 265V

• Breaker Size: 20A

Energy-saving features include:

• ECONO Mode for reduced electricity usage

• PAM Control for efficient power regulation

• Inverter compressor for variable-speed operation

• Good Sleep Off Timer for nighttime efficiency

• Indoor quiet operation for reduced energy waste

Wide Voltage Operation for Stable Performance

One of the standout features of this AC is its wide voltage operating range (160V–265V), allowing it to perform reliably in areas with voltage fluctuations.

• Protects compressor and internal components

• Ensures consistent cooling performance

• Reduces dependency on voltage stabilizers

• Suitable for regions with unstable electricity supply

Eco-Friendly R32 Refrigerant

This air conditioner uses R32 refrigerant, which offers:

• Higher energy efficiency

• Lower environmental impact

• Reduced global warming potential

• Improved heat transfer performance

Smart Features & Convenience

This AC includes multiple smart and user-friendly features:

• Auto Restart Function: Automatically resumes operation after power outages

• Timer Function: Schedule on/off operation as needed

• Sleep Mode: Maintains comfortable temperature during night-time

• Quiet Operation Mode: Ensures low noise during operation

• Backlit Remote Control: Easy operation even in low light

These features make the AC convenient and easy to use in daily life.

Quiet Operation for Comfortable Environment

This air conditioner operates with low noise levels, making it suitable for bedrooms, offices, and quiet environments.

• Indoor Noise Levels:

  • High: 45 dBA

  • Medium: 40 dBA

  • Low: 35 dBA

• Outdoor Noise Level: 54 dBA

The quiet performance ensures minimal disturbance while maintaining effective cooling.

Flexible Installation Options

• Maximum Piping Length: 20 meters

• Maximum Height Difference: 10 meters

• Mounting Type: Wall-mounted split system

This flexibility allows installation in various room layouts and building configurations.

Compact and Durable Design

Indoor Unit:

• Dimensions: 310 mm (H) × 1100 mm (W) × 239 mm (D)

• Weight: 16 kg

Outdoor Unit:

• Dimensions: 595 mm (H) × 845 mm (W) × 300 mm (D)

• Weight: 42 kg

The design is both compact and durable, ensuring long-lasting performance and easy integration into modern interiors.

Included Installation Accessories

• Indoor unit

• Outdoor unit

• Remote control with backlight

• User manual & warranty card

• Standard installation kit

• Connecting wires (limited length)

These accessories simplify installation and setup.

Applications

This 5.28 kW inverter AC is suitable for:

• Medium to large bedrooms

• Living rooms

• Offices and meeting rooms

• Shops and showrooms

• Areas requiring stable cooling with voltage fluctuation support

Warranty & Reliability

This air conditioner comes with reliable warranty coverage:

• 5 Years Compressor Warranty

• 1 Year Spare Parts Warranty

• Free Service Warranty

This ensures long-term reliability and peace of mind.

Why Choose This 5.28 kW Inverter Air Conditioner?

• 18,000 BTU efficient cooling capacity

• Inverter technology for optimized energy usage

• Wide voltage operation (160V–265V)

• ECONO Mode for energy savings

• PAM control for stable performance

• Dual swing airflow for uniform cooling

• Quiet indoor operation

• Eco-friendly R32 refrigerant

• Flexible installation options

• Strong warranty support

Long-Term Benefits

• Reduced electricity consumption

• Stable cooling even during voltage fluctuations

• Improved indoor comfort

• Lower maintenance requirements

• Durable and reliable performance

Installation Requirements

For optimal performance:

• Proper wall space for indoor unit

• Adequate ventilation for outdoor unit

• Stable electrical supply (160V–265V supported)

• Professional installation recommended

Conclusion

This 5.28 kW (18,000 BTU) inverter split air conditioner is a powerful and energy-efficient cooling solution designed for modern homes and workplaces. With advanced features such as inverter technology, wide voltage operation, ECONO mode, PAM control, dual swing airflow, and smart convenience functions, it delivers consistent cooling performance while maintaining efficiency and reliability.

Its eco-friendly refrigerant, quiet operation, durable build, and flexible installation options make it a dependable choice for users seeking long-term comfort and value. Whether for residential or commercial use, this AC ensures stable performance, reduced energy consumption, and enhanced indoor comfort throughout the year.
