2 Ton Split Air Conditioner (24200 BTU) – High Performance Cooling with Power Chill Mode, Energy Efficiency, Smart Airflow & Advanced Comfort Features

Experience superior cooling performance with this 2 Ton Split Air Conditioner, designed to deliver powerful, efficient, and reliable cooling for large residential and commercial spaces. With a cooling capacity of up to 25,600 BTU (7.5 kW max), this AC ensures rapid temperature reduction, stable operation, and consistent comfort even in extreme weather conditions.

Built with advanced cooling technologies such as Power Chill Operation, Econo Mode, Coanda Airflow, and PAM Control, this air conditioner combines high performance with energy-saving capabilities. Whether you are cooling a large living room, office, showroom, or commercial area, this AC is engineered to meet demanding cooling requirements with efficiency and precision.

Powerful Cooling Performance for Large Spaces

This air conditioner is designed for heavy-duty cooling applications with a wide operating range.

• Cooling Capacity: 7.1 kW (Min: 2.1 ~ Max: 7.5 kW)

• BTU Range: 7,200 ~ 25,600 BTU/h

• Ideal for: Large rooms, offices, halls, and commercial environments

It provides fast cooling and maintains consistent indoor temperatures even under high ambient heat conditions.

Multiple Cooling Modes for Enhanced Comfort

This AC includes several intelligent cooling modes to suit different usage scenarios:

• Power Chill Operation: Rapid cooling for quick temperature reduction

• Econo Mode: Energy-saving operation for reduced electricity consumption

• Good Sleep Mode: Optimized cooling for night-time comfort

• Indoor Quiet Operation: Minimizes noise for a peaceful environment

These modes allow users to customize cooling based on comfort, energy efficiency, and time of use.

Advanced Airflow System for Uniform Cooling

The AC is equipped with a high-performance airflow system that ensures even air distribution throughout the room.

• Airflow Rate: 20.4 m³/min (720 CFM)

• Vertical Auto Swing (Up & Down)

• Horizontal Auto Swing (Left & Right)

• Coanda Airflow Technology

The Coanda airflow helps direct cool air along the ceiling, ensuring uniform cooling without direct airflow discomfort.

Energy Efficient Operation with Smart Control

This air conditioner is designed for optimized energy usage while maintaining powerful performance.

• Power Consumption:

  • Standard: 2410W

  • Range: 600W (Min) ~ 3100W (Max)

• Power Supply: 1 Phase, 230V, 50Hz

• Operating Voltage Range: 160V ~ 265V

Features like Econo Mode and PAM Control help reduce energy consumption while maintaining efficient cooling performance.

Smart Power & Electrical Performance

• Breaker Size: 20A

• Estimated Running Current: ~10.5A

• Power Input: 2410W (Nominal)

The AC is designed to handle voltage fluctuations and operate reliably in different power conditions.

Eco-Friendly R32 Refrigerant

This air conditioner uses R32 refrigerant, known for:

• High energy efficiency

• Lower environmental impact

• Better cooling performance

• Reduced global warming potential compared to older refrigerants

Durable Design & Flexible Installation

• Mounting Type: Wall-mounted indoor unit

• Remote Control: Backlit remote for easy operation

Installation Flexibility:

• Maximum piping length: 30 meters

• Maximum height difference: 20 meters

• Suitable for various installation layouts

Compact Indoor & Outdoor Units

Indoor Unit:

• Dimensions: 310 x 1100 x 239 mm

• Weight: 18 kg

Outdoor Unit:

• Weight: 47 kg

• Designed for durability and efficient heat dissipation

The compact and modern design allows seamless integration into different environments.

Quiet Operation for Comfortable Living

This AC is engineered for low noise performance, ensuring a peaceful indoor environment.

• Indoor Noise Levels:

  • High: 49 dBA

  • Medium: 47 dBA

  • Low: 45 dBA

  • Lower speeds: 42 dBA / 39 dBA

• Outdoor Noise Level: 58 dBA

The quiet operation makes it suitable for bedrooms, offices, and study areas.

Smart Features & Convenience

• Good Sleep Off Timer: Automatically adjusts temperature for night comfort

• Auto Restart Function: Resumes operation after power outages

• Backlit Remote Control: Easy operation in low light

• Multiple Fan Speeds: Adjustable comfort levels

• Quiet Mode: Reduced noise for better sleep and productivity

Warranty & Reliability

This air conditioner comes with strong warranty coverage:

• 5 Years Compressor Warranty

• 1 Year Spare Parts Warranty

• Free Service Warranty

This ensures long-term reliability and peace of mind for users.

Applications

This 2 Ton AC is ideal for:

• Large living rooms

• Offices and conference rooms

• Restaurants and showrooms

• Commercial and industrial spaces

Its high cooling capacity makes it suitable for demanding environments.

Why Choose This 2 Ton Split Air Conditioner?

• High cooling capacity up to 25,600 BTU

• Power Chill Mode for fast cooling

• Energy-saving Econo Mode

• Coanda airflow for uniform cooling

• Advanced inverter/PAM control technology

• Wide voltage operating range (160V–265V)

• Eco-friendly R32 refrigerant

• Quiet indoor and outdoor operation

• Flexible installation with long piping support

• Reliable warranty coverage

Long-Term Benefits

• Efficient cooling with optimized energy use

• Reduced electricity bills

• Comfortable indoor environment

• Durable and long-lasting performance

• Suitable for both residential and commercial use

Installation Requirements

For optimal performance:

• Proper wall space for indoor unit

• Adequate ventilation for outdoor unit

• Stable electrical connection (230V, 50Hz)

• Professional installation recommended

Conclusion

This 2 Ton Split Air Conditioner (24200 BTU) is a high-performance cooling solution designed for large spaces requiring powerful and reliable cooling. With advanced features like Power Chill Mode, Coanda airflow, Econo Mode, and smart sleep functions, it delivers both comfort and efficiency.

Its durable build, eco-friendly refrigerant, flexible installation options, and strong warranty make it a dependable choice for homes, offices, and commercial environments. Upgrade your cooling system with this advanced AC and enjoy consistent comfort, energy efficiency, and long-term reliability throughout the year.
